ModelBegin
GeometrySampling Solid
ProtoBegin Base
LightSampling Facet
Surface 0.7 0.6 0.8
Color 0.0 0.0 1.0
Cylinder 0.2 1.0 0.6 6
Translate 0.0 0.2 0.0
Cylinder 0.2 0.6 0.6 6
Translate 0.0 0.2 0.0
Cylinder 0.0 0.6 0.3 6
Color 0.9 0.0 0.0
LightSampling Vertex
Hemisphere 0.3 3
ProtoEnd
ProtoBegin Finger
Surface 0.6 0.4 0.8
Color 0.5 0.5 0.5
LightSampling Facet
Translate 0.0 0.35 0.0
Block 0.3 0.4 0.1
TransformBegin
Translate 0.0 0.2 0.0
TransformBegin
Color 0.9 0.0 0.0
LightSampling Vertex
Rotate 0.0 0.0 1.0 90.0
Translate 0.05 -0.15 0.0
Cylinder 0.3 0.05 0.05 6
Disc 0.0 -0.05 6
Disc 0.3 0.05 6
TransformEnd
Translate 0.0 0.05 0.0
ClumpBegin
Color 0.5 0.5 0.5
LightSampling Facet
Translate 0.0 0.2 0.0
Block 0.3 0.3 0.1
ClumpEnd
TransformEnd
ProtoEnd
ProtoBegin Hand
Surface 0.6 0.4 0.8
Color 0.9 0.0 0.0
LightSampling Vertex
Sphere 0.15 3
TransformBegin
RotateJoint 1.0 0.0 0.0 -30.0
ClumpBegin
ProtoInstance Finger
ClumpEnd
RotateJoint 1.0 0.0 0.0 60.0
ClumpBegin
ProtoInstance Finger
ClumpEnd
TransformEnd
ProtoEnd
ProtoBegin UpperArm
Surface 0.6 0.4 0.8
Color 0.0 0.9 0.0
LightSampling Vertex
Disc 0.0 -0.3 6 # upper arm geometry
Cylinder 2.0 0.3 0.2 6 # upper arm geometry
Disc 2.0 0.2 6 # upper arm geometry
Translate 0.0 2.2 0.0
MaterialBegin
Color 0.9 0.0 0.0
Sphere 0.2 3
MaterialEnd
RotateJoint 1.0 0.0 0.0 100.0
ClumpBegin # fore-arm contained in the upper arm
Translate 0.0 0.2 0.0 #
Disc 0.0 -0.2 6 # fore arm geometry
Cylinder 2.0 0.2 0.15 6 # fore arm geometry
Disc 2.0 0.15 6 # fore arm geometry
Translate 0.0 2.15 0.0 #
RotateJoint 1.0 0.0 0.0 40.0 #
ClumpBegin # hand connected to fore arm
ProtoInstance Hand #
ClumpEnd #
ClumpEnd #
ProtoEnd
RotateJoint 0.0 1.0 0.0 30.0
ClumpBegin
Scale 0.4 0.4 0.4
ProtoInstance Base
TransformBegin
Translate 0.0 0.4 0.0
RotateJoint 1.0 0.0 0.0 -45.0
ClumpBegin
Translate 0.0 0.3 0.0
ProtoInstance UpperArm
ClumpEnd
TransformEnd
ClumpEnd
ModelEnd
